Upgrade Waste Water Treatment 1


IONEX A oder B

Flow-through version with discharge into canalisation

  • Removal of solids and all heavy metals → waste water regulations can be met!
  • Decrease of chemical oxygen demand
  • PH neutralization by minerals
  • For post treatment of etch and galvanic rinse water
  • Lower and upper sump level control switch
  • 2 different standard sizes
  • Special solutions on request
  • Machine is connected to etch-, developer- or PTH-machine
  • Waste water from these plants is collected in the IONEX
  • Tank capacity: max. 110 l (max. 220 l IONEX B)
  • Cleaning capacity: approx. 100 (200 IONEX B) Eurocards or 1000 (2000 IONEX B ) prerinsed Eurocards
  • Water throughput: 10 l/h (15 l/h IONEX B)
  • Consumption of neutralizing agent: approx. 100ml on 100l waste water
  • 4 cleaning steps:
    • coarse filter
    • cotton micro filterneutralisation column to adjust ph-value
    • 2 cation exchanger columns to remove heavy metal ions
    • neutralisation column to adjust ph-value
  • Cleaned rinsing water is discharged into the canalisation
